Technical Parameters
Breathing mode:A/C,SIMV,MANUAL
Tidal volume:100ml-1800ml
Ventilation frequency:4-80bpm
Spont ventilation switch pressure:6-40cmH2O
Airway pressure upper limit:20-80cmH2O
Airway pressure lower limit:0-20cmH2O
Inspiratory time:0.3s-2s
I/E ratio:1:1-1:5
Trigger pressure:0- -20cmH2O
Oxygen concentration:50% or 100%
Airway safety pressure:45cmH2O or 60cmH2O
Gas supply pressure:0.28-0.6Mpa
Inner lithium battery:"Lithium battery DC7.2v2.2Ah,
can works for more than 15hours"
Charger:AC110-220v 50-60HZ
Dimension:185×90×56mm
Weight:1.0kg
◆All specifications are subject to a tolerance of +/-15%.

Product Features
◆Multiple ventilation modes
◆Manual button used during CPR
◆LCD display
◆Multiple visual and audible alarms
◆LED state indicator
◆Electro-pneumatically controlled,time/pressure switched and micro-processor monitored
◆Compact,portable,lightweight,durable design

Monitoring Parameters
◆Tidal volume
◆Peak pressure
◆Ventilation frequency
◆Minute ventilation volume
◆Spont ventilation trigger indicator

Alarm
◆Low airway pressure alarm
◆High airway pressure alarm
◆Low battery
◆Alarm silent:120s

LCD Display
◆Tidal volume
◆Minute ventilation
◆Oxygen concentration
◆Trigger indicator
◆Peak airway pressure
◆Recharge indicator
◆Total ventilation frequency

Kits
Ventilator(including air-oxygen mixer,automatic airway pressure relief valve),oxygen cylinder,regulator,face mask,suction device,suction union pipe,airway opener,oxygen refill fitting,oxygen supply extension pipe,wrench,portable nylon bag or hard case.
